BEAM & PLATE DRILL LINE MACHINERY
1994 PEDDINGHAUS Fully Automatic 3-Axis Structural Steel Drilling Line, Mdl. TDK 1000/9, s/n 4756971994005, Siemens 840 C control system, vertical web drill assembly w/(3) spindles, (2) horizontal flange drill assembly, Peddimat roller feed measuring system w/measuring discs, automatic hold down on in-feed and discharge side, automatic hydraulically operated drill feed, 300 mm spindle stroke, 40 mm max. drill diameter, 9 mm min. drill diameter, (9) total drill spindles, (3) per axis, 25–350 mm/min. variable feed rate, 17,500-lbs. max. beam weight, 420 mm max. beam height 1,000 mm max. beam width.
1995 PEDDINGHAUS 2-Axis Horizontal Plate Drilling and Cutting Machine, Mdl. FDB-150D, s/n 475877529002, Mdl. Sinumerik 840 C Siemens control, (3) drill spindles, 8–40 mm drill diameters, 1500 x 50 mm flat bar/plate size, 1500 x 50 mm material pass through size, 300 mm stroke capacity, 25–250 mm feed rate, Hypertherm plasma cutting system 200–750 mm cutting speed, 20 mm material positioning speed.
1992 BEHRINGER Vertical Post Type Hydraulic Horizontal Band Saw, Mdl. HBP-530/1100 G, s/n 389118, 19.6" beam height capacity cut, 43.3" beam width capacity cut, 20.8" round stock capacity cut, 17–110 mm variable cutting speed, 90? mitre cutting, 10 HP motor.
IRON WORKERS/PUNCHES
PIRANHA Iron Worker, Mdl. P-90, s/n P4-430, 90-ton capacity punch, 12" capacity break, 20" shear capacity, corner notcher, square shear.
PIRANHA Iron Worker, Mdl. P-50, s/n 5656, 50-ton capacity punch, 8" capacity break, 15" shear capacity.
1992 PIRANHA Punch, Mdl. 120, s/n 120-085, 120-ton capacity, 21" throat capacity 22" x 72" material table.
1985 PIRANHA Punch, Mdl. 120, s/n 120-392, 120-ton capacity, 21" throat capacity "no table."
MACHINE SHOP/SAWS
BRIDGEPORT Milling Machine, Mdl. J-head, s/n 48558, 1 HP, variable speed 80–2,700, 9" x 42" auto feed table, draw bar, coolant mister.
