CNC STONE & TILE FABRICATOR MACHINE

2014 NORTHWOOD Mdl. 138EDS 4-Axis Stone and Tile Fabrication Machine, s/n 12358, Fanuc Oi-MD CNC control w/integrated PC, Stone Vision software w/Alphacam engine/built-in tool wizard, slab smith program, stone laser part/pod Carter Mdl. LP-HFD Z-axis laser positioning system, 15 kW Northwood/Fanuc ED spindle (sk40 chuck) w/(32) tool positions, (26) Blick vacuum pods for part holding w/(4) remote vacuum manifolds, (13) different edge profiles, texturing head, 5 CM material cut capacity, 156" x 96" work area, 14" direct drive high-torque 2-axis smart saw, 360? programmable C-axis, power tilt for 45? miter cuts, stone scan barcode data input/wireless barcode reader, programming laptop for off-line programming, Super Z technology tooling, automatic backup system for CNC control, 5 HP vacuum system.

BRIDGE SAW

2005 ZONATO Mdl. FPZ-500 Stone Bridge Saw, s/n 5281, 20 HP saw motor, 20" blade diameter, hydraulic tilt table, rotating in any position, 138" max. cut length, 5-3/16" max. cutting depth, performs miter cuts, 90? blade tilt, powered cross travel w/variable speed, 141" x 80" cutting table.

STONE EDGE POLISHERS

2003 MONTRESOR Mdl. Lara-80-52 Stone Edge Polishing Machine, s/n 200-338, Siemens Mdl. Simatic OP17/PP17 control, 10-position/ finishing stations, auto. material feed, water cooled polishing.

1998 MARMO MECCANICA Mdl. LCV711M Stone Edge Polisher, s/n 5240, 12" polishing belt, 9-position polishing stations, auto. feed material, water cooled polishing.

WATER TREATMENT PLANT

2005 MATEC Water Treatment Plant, “Pristine Water Treatment” refurbished the machine in 2013, everything but the tank, 300,000-galllon monthly recirculation rate, flocculent chemical separation unit.

SUPPORT EQUIPMENT

INGERSOLL RAND Mdl. IRN40H-CC-HV Rotary Screw Air Compressor, s/n CBV286
