PRECISION AUTOMOTIVE MACHINE SHOP
On the premises of
TRI VALLEY MACHINE






Details

Starts: TUESDAY, JANUARY 8 AT 11:00 A.M.


120 S BUCHANAN CIRCLE
PACHECO, CALIFORNIA 94553
View Map

Auction Type: Public Auction

Auction Highlights:
Cylinder & Horizontal Honing Machines, Seat & Guide Machine, Valve Refacing Machine, Sunnen Hone, Boring Bars, Head & Block Surfacing Mills, Flywheel Grinder, Balancing Machines, Support Equipment, Tooling & More!

Contact Information

Contact:  Ryan Ashman
Phone:  (925) 256-8111
Fax:  (925) 256-8436

Description

CYLINDER HONING MACHINE

SUNNEN Mdl. CV-616 Automatic Cylinder Honing Machine, w/CK-3155A cylinder diameter setting fixture for shim and guide set-up, CK-3355A stone inserting and removal fixture, conventional automotive engine block mounting equipment.

HORIZONTAL HONING MACHINE

SUNNEN Mdl. CH-100 "Line-Hone" Horizontal Honing Machine, w/conventional automotive engine block hold down fixturing, oil system and mandrel drive.

SEAT & GUIDE MACHINE

SUNNEN Mdl. VGS-20 , White Painted Series, w/late electrical control system, infinitely variable spindle speed control, tilting workhead, 360 degree rotating cylinder head clamping fixture, w/fine adjust, electronic valve guide level.

VALVE REFACING MACHINE

SUNNEN Mdl. VR-8000K Valve Refacing Machine, "Centerless" Type, w/8" face and stem grinding wheels, coolant reservoir and floor stand.

SUNNEN HONE

SUNNEN Mdl. LBB-1810 "Power-Stroker" Hone Machine, w/LBB-1810 power operated 6-speed floor model honing machine, conventional ring set, AG-300 precision gage, CRG-750 cap and rod grinder, TN-111 rod aligner.

BORING BARS

KWIK-WAY Mdl. FN Portable Cylinder Boring Bar, w/ standard tooling and manual centering, 3/4 hp. motor, (2) spindle speeds, (2) feed rates and semi-auto spindle retract, boring dia. range: 2.65"–5.33", stroke length: 14 1/2".

KWIK-WAY Mdl. FL Portable Cylinder Boring Bar, w/ standard tooling and manual centering, 3/4 hp. motor, four spindle speeds, four feed rates and semi-auto spindle retract, boring dia. range: 3.0"–6.75", stroke length: 18".

KWIK-WAY Mdl. EBF Cylinder Boring Stand For In-Line and V-Blocks, w/conventional set of main housing adapters, T-slot type boring bar mounting surface, 90 degree block roll-over capacity (45 degree for each bank) without air float system.

HEAD & BLOCK SURFACING MILLS

STORM-VULCAN Mdl. 85B-E Cylinder Head and Block Surfacing Mill, w/18" cutting head, (16) adjustable/ indexable carbide cutting tips, universal cylinder head mounting equipment, in-line and V-block mounting equipment, 2-speed spindle and infinitely variable fee.

STORM-VULCAN Mdl. 85-E Cylinder Head Surfacing Mill, w/18" cutting head, (16) brazed carbide cutting tips, universal cylinder head mounting equipment, 2-speed spindle and infinitely variable feed rate.

FLYWHEEL GRINDER

NORMAN FG-5000 Flywheel Grinder, w/5 hp. grinding.

BALANCING MACHINE

STEWART WARNER Mdl. 2000 Electronic Balancing Machine, connecting rod weighing fixture w/base, staff, cross-arm and ball bearing pin bore and bearing housing adapter.

STEWART-WARNER "Shadow-Graph" Electronic Scale, 3,000 gram capacity and one gram resolution.

SUPPORT EQUIPMENT

SUNNEN Mdl. TS-100 Cutting Tool Lapping Machine, w/ tilting/sliding bed and locking swivel tool guide and infinitely variable speed spindle, 6" diamond faced lapping wheels.


SUNNEN Mdl. BP-10 Electric/Hydraulic Bench Top Piston Pin Press, 10-ton capacity, w/standard bed plate adapter.


SUNNEN Mdl. CRH-50 Electric, w/twin timer operated temperature controllers and capacity for (2) connecting rods.


TOBIN-ARP Mdl. CB-24000 Overhead Cam Bearing Align Boring Machine, w/standard 3/4" diameter x 28" length boring bar, belt change-type 6-speed spindle, air/ hydraulic infinitely variable feed rate control and combination floor stand.


ATE (Automotive Test Equipment ) Mdl. HSO Cylinder Head Straightening Oven, w/welded steel straightening fixture, electric heat, hinged diagonal opening lid w/latch, full cabinet fiberglass blanket insulation, cycle timer and temperature gauge.


AXE Mdl. ESTD-40 Combination Engine Stand Tear Down Cart , 10-gallon steel construction, 32" x 44" upper and lower platforms, sloped upper platform, w/bung for fluid drainage, 1,000-lb. load capacity, rubber tire casters and mounting bolt storage.


AXE Mdl. SW-20G-HT Spray Washing Machine, w/sprocket driven 20" turntable, 32" workpiece height capacity, gas heating system and 21" x 30" x 11" height series front hot tank compartment. Reservoir capacity: 80-gallons.

AXE Mdl. SW-40G-EX Spray Washing Machine, w/sprocket driven 28" turntable, 40" workpiece height capacity, gas heating system and 24" x 55" x 11" ht series front hot tank compartment. Reservoir capacity: 160 gallons.

AXE Mdl. RB-70 Rinse Booth, water recirculating, w/28" diameter non-powered turntable, 70-gallon reservoir, w/electric reservoir heating system, submerged recirculaing pump, 30 minute pump timer, air/water rinse gun, fresh water inlet, water source switch.


AXE Mdl. UP-1437 Cylinder Head Pressure Tester, universal w/stainless steel submering tank, full 360 degree roll-over fixture, pneumatic roll-over fixture elevating steam, (20) universal deck surface plates, side and end block-off plates, block-off plate B.

TOOLING

SUNNEN Mdl. GA-2125 Dial Bore Gage, w/.0005" resolution, 12" reach.

SUNNEN Mdl. CF-1126 Dial Bore Gage Setting Fixture, w/.0001" reading micrometer head, dia. range of 2"–8", 2" ring gage master standard, (3) range setting standards as follows: CF-220A, range: 2"–3", CF-230A.


SUNNEN Honing Mandrel Mdl. 10RY-1800F for CH-100 "Line Hone", steel body, w/(10) stones and (20) shoes, range: 2.1"–2.4".

SUNNEN Mdl. 10RY-1800F Honing Mandrel for CH-100 "Line Hone", steel body, w/(10) stones and (20) shoes, range: 1.8"–2.1".

SUNNEN Honing Mandrel Mdl. 10RY-1800F for CH-100 "Line Hone", aluminum body, w/(10) stones and (20) shoes, range: 2.4"–2.7".

SUNNEN Honing Mandrel Mdl. 10RY-2700F for CH-100 "Line Hone", aluminum body, w/(10) stones and (20) shoes, range: 2.7"–3.0".

Inspection Equipment; Power Tools; Hand Tools; Partial Listing.


Preview/Inspection

Morning of Sale, 9:00 A.M. to 11:00 A.M.

Directions

FROM WALNUT CREEK: Take I-680 North. Merge onto CA-4 West and take the Pacheco Blvd. exit and turn right. Turn left on South Buchanan Circle. Look for "Auction Today" Signs.
